Kite Series

Sophisticated looks, unique patented design & unmatched brightness; Samudra’s Kite Series Brings to you the street light of the future.

Download Files

H0 15W

Specification SAMKITSL0XP15**
 Power 15 Watt
 Input Voltage AC 100 - 304 V 50/60Hz
 PF >= 0.93
 CCT 2400 - 6000K
 *Luminous Flux (Lm) 2006
 Total System Efficacy 113  Lm/W
 Surge Protection Up to 4 KV (Optional 10 KV)
 CRI 70
 Net Weight ~0.9 kg
 Life Span > 50000 hrs.
Certifications/Test Reports ROHS/IP66 Luminaire/LM79/Vibration/IK07 as per IEC 62262/ IP67 Drivers
*Luminous Flux mentioned above is for CCT: 5600K
** X represents color tempreture. It is C: Cool white, W: Warm white & D: Day light
Note
  1. Samudra LED uses only LM80 Certified LEDs.
  2. A variation of + 3% is possible in some of the above figures.
  3. Due to continuous change in technology, product is subject to change without prior notice.

Download Files

H0 25W

Specification SAMKITSL0XP25**
 Power 25 Watt
 Input Voltage AC 100 - 304 V 50/60Hz
 PF >= 0.93
 CCT 2400 - 6000K
 *Luminous Flux (Lm) 2840
 Total System Efficacy 121 Lm/W
 Surge Protection Up to 4 KV (Optional 10 KV)
 CRI 70
 Net Weight ~0.9 kg
 Life Span > 50000 hrs.
Certifications/Test Reports ROHS/IP66 Luminaire/LM79/Vibration/IK07 as per IEC 62262/ IP67 Drivers
*Luminous Flux mentioned above is for CCT: 5600K
** X represents color tempreture. It is C: Cool white, W: Warm white & D: Day light
Note
  1. Samudra LED uses only LM80 Certified LEDs.
  2. A variation of + 3% is possible in some of the above figures.
  3. Due to continuous change in technology, product is subject to change without prior notice.

Download Files

H1 30W

Specification SAMKITSL1XP30**
 Power 30 Watt
 Input Voltage AC 100 - 304 V 50/60Hz
 PF >= 0.93
 CCT 2400 - 6000K
 *Luminous Flux (Lm) 4079
 Total System Efficacy 151  Lm/W
 Surge Protection Up to 4 KV (Optional 10 KV)
 CRI 70
 Net Weight ~1.6 kg
 Life Span > 50000 hrs.
Certifications/Test Reports ROHS/IP67/Thermal/ Endurance/ITHD/IES-LM79/Vibration/ IP67 Drivers
*Luminous Flux mentioned above is for CCT: 5243K
** X represents color tempreture. It is C: Cool white, W: Warm white & D: Day light
Note
  1. Samudra LED uses only LM80 Certified LEDs.
  2. A variation of + 3% is possible in some of the above figures.
  3. Due to continuous change in technology, product is subject to change without prior notice.

Download Files

H1 40W

Specification SAMKITSL1XP40**
 Power 40 Watt
 Input Voltage AC 100 - 304 V 50/60Hz
 PF >= 0.93
 CCT 2400 - 6000K
 *Luminous Flux (Lm) 4896
 Total System Efficacy 130  Lm/W
 Surge Protection Up to 4 KV (Optional 10 KV)
 CRI 70
 Net Weight ~2.4 kg
 Life Span > 50000 hrs.
Certifications/Test Reports ROHS/IP67/Thermal/ Endurance/ITHD/IES-LM79/Vibration/ IP67 Drivers
*Luminous Flux mentioned above is for CCT: 5200K
** X represents color tempreture. It is C: Cool white, W: Warm white & D: Day light
Note
  1. Samudra LED uses only LM80 Certified LEDs.
  2. A variation of + 3% is possible in some of the above figures.
  3. Due to continuous change in technology, product is subject to change without prior notice.

Download Files

H1 50W

Specification SAMKITSL1XP50**
 Power 50 Watt
 Input Voltage AC 100 - 304 V 50/60Hz
 PF >= 0.93
 CCT 2400 - 6000K
 *Luminous Flux (Lm) 6765
 Total System Efficacy 128  Lm/W
 Surge Protection Up to 4 KV (Optional 10 KV)
 CRI 70
 Net Weight ~2.4 kg
 Life Span > 50000 hrs.
Certifications/Test Reports ROHS/IP67/Thermal/ Endurance/ITHD/IES-LM79/Vibration/ IP67 Drivers
*Luminous Flux mentioned above is for CCT: 5400K
** X represents color tempreture. It is C: Cool white, W: Warm white & D: Day light
Note
  1. Samudra LED uses only LM80 Certified LEDs.
  2. A variation of + 3% is possible in some of the above figures.
  3. Due to continuous change in technology, product is subject to change without prior notice.

Download Files

H2 70W

Specification SAMKITSL2XP70**
 Power 70 Watt
 Input Voltage AC 100 - 304 V 50/60Hz
 PF >= 0.93
 CCT 2400 - 6000K
 *Luminous Flux (Lm) 9466
 Total System Efficacy 132 Lm/W
 Surge Protection Up to 4 KV (Optional 10 KV)
 CRI 70
 Net Weight ~3.0 kg
 Life Span > 50000 hrs.
Certifications/Test Reports ROHS/IP67/Thermal/ Endurance/ITHD/IES-LM79/Vibration/ IP67 Drivers
*Luminous Flux mentioned above is for CCT: 5400K
** X represents color tempreture. It is C: Cool white, W: Warm white & D: Day light
Note
  1. Samudra LED uses only LM80 Certified LEDs.
  2. A variation of + 3% is possible in some of the above figures.
  3. Due to continuous change in technology, product is subject to change without prior notice.

Download Files

H2 80W

Specification SAMKITSL2XP80**
 Power 80 Watt
 Input Voltage AC 100 - 304 V 50/60Hz
 PF >= 0.93
 CCT 2400 - 6000K
 *Luminous Flux (Lm) 9737
 Total System Efficacy 127 Lm/W
 Surge Protection Up to 4 KV (Optional 10 KV)
 CRI 70
 Net Weight ~3.0 kg
 Life Span > 50000 hrs.
Certifications/Test Reports ROHS/IP67/Thermal/ Endurance/ITHD/IES-LM79/Vibration/ IP67 Drivers
*Luminous Flux mentioned above is for CCT: 5000K
** X represents color tempreture. It is C: Cool white, W: Warm white & D: Day light
Note
  1. Samudra LED uses only LM80 Certified LEDs.
  2. A variation of + 3% is possible in some of the above figures.
  3. Due to continuous change in technology, product is subject to change without prior notice.

Download Files

H2 90W

Specification SAMKITSL2XP90**
 Power 90 Watt
 Input Voltage AC 100 - 304 V 50/60Hz
 PF >= 0.93
 CCT 2400 - 6000K
 *Luminous Flux (Lm) 12315
 Total System Efficacy 85-135 Lm/W
 Surge Protection Up to 4 KV (Optional 10 KV)
 CRI 70
 Net Weight ~3.0 kg
 Life Span > 50000 hrs.
Certifications/Test Reports ROHS/IP67/Thermal/ Endurance/ITHD/IES-LM79/Vibration/ IP67 Drivers
*Luminous Flux mentioned above is for CCT: 5300K
** X represents color tempreture. It is C: Cool white, W: Warm white & D: Day light
Note
  1. Samudra LED uses only LM80 Certified LEDs.
  2. A variation of + 3% is possible in some of the above figures.
  3. Due to continuous change in technology, product is subject to change without prior notice.

Applications

Features Advantages

  • Easy To Install
  • Superior Light Quality
  • Excellent Heat Management for Longer Life
  • Mercury free: Eco-Friendly green Technology
  • India Patented Design
  • Highly energy efficient: Reduces electricity bills.
  • Instant ON/OFF (even at low voltage)
  • Manufactured in the State-of-the-art Factory at MIDC Baramati, Pune by pioneers and patent holder in LED technology.
